5
SAFETY PRECAUTIONS
GAME SPECIFICATIONS
WEIGHT
NET WEIGHT 1000lbs. 454 kg
SHIP WEIGHT 1270 lbs. 576 kg
GAME DIMENSIONS
WIDTH 61" 155 cm
DEPTH 112" 285 cm
HEIGHT 108" 275 cm
OPERATING TEMPERATURE
FAHRENHEIT 45 - 80 F
CELSIUS 7.2 - 26.7 C
SHIPPING DIMENSIONS
PALLET # 1 76”x 54”x 86” 860 lbs. class 125
PALLET # 2 76”x 34”x 86” 410 lbs. class 250
POWER REQUIREMENTS
INPUT VOLTAGE
RANGE
100 to 120
VAC
220 to 240
VAC
INPUT FREQUENCY
RANGE
60 Hz
50 Hz
MAX OPERATING CURRENT
3.3 AMPS @ 115 VAC / 1.9 AMPS @ 230VAC
