245
•
Owner’s Manual
Supplement
Chapter 6: Plumbing
39
Drain Systems
Deck Drains
• Water on the deck is drained overboard through the deck drains.
• Keep the deck drains free of debris.
Gray Water Gravity Drains
The galley sink is above the waterline and are gravity drained overboard
Sump Pump System (If Equipped)
• The shower drains into
the sump pump box.
• The sump pump box has
an autofloat switch.
• When the drain water
rises to a preset level, the
autofloat switch turns
On the sump pump, and
the drain water is
pumped overboard.
Sump Box Cleaning
Periodically clean the sump box (A), filter, and pump as follows:
1. Remove the cover screws (B) and the cover (C).
2. Remove any debris from the box and the filter.
3. Clean the sump pump as outlined in the Bilge Pump section of
this manual.
Sump System Winterization
Drain the sump pump system in the months when not in use.
1. Disconnect and drain all lines to the unit.
2. Remove the screws from the mounting feet (D) and drain
the system.
3. Reinstall the screws in the mounting feet and reconnect the system.
SUMP PUMP
SHOWER
DRAIN
OVERBOARD
THRU-HULL
BOX
A
B
D
C
