1-3
MX67QMD
Onboard I/O
Headers
■ 2 x USB 2.0 pinheaders (4 ports)
■ 1 x Amplifi er pinheader
■ 3 x COM port connectors
■ 1 x GPIO pinheader
■ 1 x LVDS connector
■ 1 x Front audio pinheader
■ 1 x Chassis intrusion pinheader
■ 1 x SPDIF pinheader
Form Factor ■ 6.7” (L) x 6.7” (W)
Power Type ■ 20 + 4-pin
ATX Power
Mechanical
and
Environment
■ Operating Temperature: -10
o
C to 60
o
C
■ Storage Temperature: -20
o
C to 80
o
C
■ Humidity: 0% ~ 90% RH, Non-Condensing
