￭ Hardware Setup
2-4
Memory
▶ Installing Memory Modules
1. Locate the SO-DIMM slot. Align the notch on the DIMM with the key on
the slot and insert the DIMM into the slot.
2. Push the DIMM gently downwards until the slot levers click and lock
the DIMM in place.
3. To uninstall the DIMM, fl ip the slot levers outwards and the DIMM will
be released instantly.
Important
You can barely see the golden fi nger if the memory module is properly in-
serted in the DIMM slot.
