BCM Advanced Research MX67QMD - Quick Components Guide

￭ Hardware Setup
2-2
Quick Components Guide
SATA Connector, p. 2-9
Mini PCIe Slot,
p. 2-18
LVDS Connector,
p. 2-14
Front Panel Pinheader,
p. 2-11
PCIe Slot,
p. 2-18
COM Power Jumper,
p.2-17
Amplifi er
Pinheader
,
p 2-10
DIMM Slot, p. 2-4
Serial Port Connector,
p. 2-13
Front USB
Pinheader,
p. 2-12
Front Audio Pin-
header, p. 2-15
Port 80 Pinheader, p. 2-15
Chassis Intrusion
Pinheader, p. 2-9
Power Connector,
p. 2-5
Clear CMOS
Jumper, p. 2-16
SATA Power Connector, p. 2-5
Fan Power Connector,
p. 2-10
GPIO
Pinheader,
p. 2-11
LVDS Power
Jumper, p. 2-17
S/PDIF Pinheader,
p. 2-15
AT/ATX Jumper,
p. 2-17
