Specifications Summary
I/O
MIO
1 x D-Sub, 1 x DVI, 1 x Gigabit LAN, 6 x USB 2.0, 2 x SATA, 4 x RS232,
5W AMP x 2-CH, 1x PS/2(KB and MS), Audio (Mic, Line in/out),1 x IDE
USB
6 x USB 2.0
DIO
8 bit digital I/O, 4 input/ 4 output
Display
Chipset
Integrated in AMD®RS690E (Radeon X1250)
Max. Resolution
2560 x 1440 bpp (@ 75Hz)
Dual Display
CRT+DVI-D
LVDS
LVDS 24Bit Dual Channel
DVI
Supported by RS690E
Audio
Audio Codec
ALC888 5.1-channel Audio Codec
Audio Interface
Mic in, Line in, Line out (3 jack)
Audio Amplifier
TPA3005D2 Stereo 5Watt per channel
Ethernet
LAN1
Realtek RTL8111C PCI-E Gigabit LAN
Ethernet Interface
LAN1 Realtek RTL8111C PCI-E Gigabit LAN
Back I/O Port
Back Panel
Double deck PS2(KB+MS)
Double deck COM(COM1+COM2) pin9 with 5V/12V selection
VGA+DVI
Double deck USB2+USB3
RJ45+2USB ports(USB0+USB1)
5.1-CH Audio I/O 3 phone jacks(Mic in, Line in, Line out)
