User’s Manual
11
Specifications Summary
Internal I/O Connector
Internal I/O
2 x USB connectors support additional 4 USB ports
1 x 20-pin ATX Power connector
1 x 4-pin ATX12V Power connector
1 x 40 pin IDE connector
2 x COM ports
2 x SATA connectors
1 x Audio amplifier connector
1 x System panel connector
1 x CPU Fan connector
1 x System Fan connector
1 x Digital IO header
Mechanical & Environmental
Power Requirement
42W (Max). ( 3.3V, 3.08A , 5V 0.817A, 5VSB 0.387A, 12V 2.18A)
Power Type
ATX
Operating Temperature
0~60°C (32~140°F)
Operating Humidity
0%~90% relative humidity, non-condensing
Size (L x W)
Mini ITX 6.69" x 6.69" (170 mm x 170 mm)
Weight
0.88 lbs (0.4 Kg)
* Specifications are subject to change without notice.
