MX945GME
Mainboard
ME, XP or a third-party IDE bus master driver). If your hard drive and your
system software both support Ultra DMA/33, Ultra DMA/66 and Ultra DMA/
100 , select [Auto] to enable BIOS support.
*** On-Chip Serial ATA Setting ***
On-Chip Serial ATA
This setting specifies the function of the on-chip SATA controller.
[Disabled]
Disable SATA controller
[Auto]
utomatically determined by BIOS
[Enhanced Mode] Enable both SATA and PATA, max.
6 IDE drives supported
[SATA Only] SATA operates in legacy mode
PATA IDE Mode / SATA Port
These settings specify the modes of the PATA & SATA ports.
Onboard Device
USB Controller
This setting is used to enable/disable the onboard USB controller.
USB 2.0 Controller
This setting is used to enable/disable the onboard USB 2.0 controller.
USB Keyboard/Mouse Support
Set to [Enabled] if your need to use a USB-interfaced keyboard/mouse in the
operating system that does not support or have any USB driver installed,
such as DOS and SCO Unix.
3-12
