zalia is the codename of “High Definition Audio.” This setting controls the
High Definition Audio interface integrated in the Southbridge.
Audio Amplifier Control
This setting disables/enables the audio amplifier.
Amplifier dB
When the Audio Amplifier Control is set to [Enabled], users may adjust
the amplifier dB range between the lowest useful output and the largest
useful output level.
Onboard Ethernet #1/ #2
These settings disable/enable the onboard Ethernet controller.
Onboard LAN1/ LAN2 Boot ROM
The items enable or disable the initialization of the onboard LAN Boot ROMs
during bootup. Selecting [Disabled] will speed up the boot process.
Super IO Device
3-13
