BD Phoenix™ M50 System Quick Reference Guide
INSTRUMENT STATUS
Door Locked Door Unlocked Idle Processing Data Warming Up Temperature
Testing
Instrument
Number
Light Source
Adjustment
(RGB, UV)
Inventory Scan
Isolation Recovery
(Uploading Data)
**BD EpiCenter™
Configured and
Connected
**BD EpiCenter™
Configured but
not Connected
*LIS Configured
and Connected
*LIS Configured
but Disconnected
Instrument
Connection Status
– Connected
(All-in-One PC to
Instrument)
Instrument
Connection Status
– Disconnected
(All-in-One PC
to Instrument)
* Icon does not appear when connected to BD EpiCenter™.
** Icon does not appear when in standalone mode.
5
