iMX113 BD Pyxis ™ ES Refrigerator Tower Operation Manual
360395/E 8
2.3 AC Power Cord
NOTICE
Use manufacturer supplied power cord only.
Install power cord
If packaged with modular cord, insert plug securely into the refrigerator power receptacle prior to connecting to
grounded outlet.
2.4 Temperature Probes
A solid ballast is installed on the upper left interior side of the unit. A temperature probe for the temperature display is inserted into
the solid ballast and secured with thumb screws.
Notes
• Temperature probes are fragile; handle with care.
• Remote probes may also be introduced through the existing port on top of unit.
The solid ballast may be relocated within the unit as necessary. Recalibration of temperature probes is recommended when the
ballast is moved from the original location. Refer to the Refrigerator Service and Maintenance manual for instructions
regarding recalibration.
