STEP 3. SECURE LEG ASSEMBLY
Insert (H7) Barrel Nut into holes of (C10) Modesty
Panel with the elongated slot sitting horizontally, and
secure with (H9) Screw through side of (A2 & A3) Legs.
NOTE: Keep screws loose until Step 4.
ASSEMBLY
PART/DESCRIPTION QTY
H7-BARREL NUT 2
H9-SCREW 2
Elongated slot
in (H7) Barrel
Nut aligns with
(H9) Screw
C10
A3
A2
H7
H9
H9
H7
H9
To Next Page
