BDS MAB 800 - Components;Scope of Supply; Machine Overview

13
Components/scope of supply
MAB 800 / MAB 840
Components/scope of supply
Machine overview
12
10
9
8
7
5
3
15
14
4
2
11
1
6
13
1 Core drill (not supplied as standard) 9 Cutting oil tank
2 Industrial holder MK3 19 mm Weldon 10 Handle
3 Morse taper MK3 11 Hand lever
4 Opening for ejector pin 12 Control panel
5 4-speed gearbox with selector 13 Rotating mechanism (MAB 840 only)
6 Speed and torque controller 14 Magnetic foot
7 Drive motor 15 Machine slide and guide
8 Filler neck for cutting oil
