31
Annex
MAB 800 / MAB 840
Annex
Technical data
Model MAB 800 / MAB 840
Dimensions (L x W x H) 366 x 239 x 725 mm
Magnetic foot (L x W) 220 x 110 mm
Net weight approx. 25 kg
Operating voltage (see type plate)
230 V / 50-60 Hz
110-125 V / 50-60 Hz
Power consumption 1800 W
Noise level 89 db(A)
Vibration 0,77 m/s²
Stroke 255 mm
Core drill, short dia. 12-100 mm
Core drill, long dia. 12-100 mm
Twist drill max. dia. 31.75 mm
Thread max. M30
Reaming max. dia. 31.75 mm
Counter-sinking max. dia. 50 mm
Speed stage 1 n
0
= 45 - 130 rpm
Speed stage 2 n
0
= 75 - 210 rpm
Speed stage 3 n
0
= 100 - 280 rpm
Speed stage 4 n
0
= 155 - 460 rpm
Overheating protection Yes
Slip clutch Yes
Variable torque Yes
Full-wave control electronics Yes
Clockwise/anti-clockwise rotation Yes
Morse taper MK3
Core drill mounting
Industrial holder MK3 19 mm Weldon
ZIA 319-M MK3
Length of the connecting lead: 2.8 m
Protection class I
