There is a relationship between the setting of the tail servo center position pulse length and the tail servo
frequency (menu point D). If a pulse length is selected that does not allow a certain frequency, this fre-
quency is automatically reduced. The center position pulse-setting always has priority, since a servo can
run without problems at a too low frequency but can not be operated with an incorrect center position
pulse.
On WWW.BEASTX.COM you can nd a list of parameters for the most common servos.
The color of the Status-LED
shows the currently selected
servo center position pulse
length:
C Tail servo center position pulse length
At setup menu point C you can select the pulse length for the tail servo‘s center position. Almost all
commercially available servos work with 1520 μs. But there are a few special tail servos on the market
which use a dierent center position pulse length.
To select the desired servo center position pulse repeatedly move the tail stick in one direction until the
Status-LED glows in the correct color.
The option “user dened” allows you to dene your own setting with the PC software.
Push the button to save the conguration and to proceed to setup menu point D.
Status-LED Tail servo center position pulse length
purple 960 μs
red 760 μs
blue 1520 μs *
o User dened
*
Factory Setting
