8. APPLICATION EXAMPLES
The following 5 pages contain schematics, showing the IPC@CHIP family microcontroller
in two applications (BECK-IPC GmbH: DK40 and FEC-FC34) and gives you three
solutions, how to handle the multi-function pin 17 RESET# / NMI / LINK-LED.
