Beck IPC@CHIP SC01 User Manual


SC01/SC02/SC11/SC12
IPC GmbH
Sc12hw09.doc page 5 of 37 24.11.1999 V0.9
TF/WB
2. PHYSICAL DIMENSIONS
3. PIN CONFIGURATION
PIO7 / RXD0
1
32
VCC
PIO8 / TXD0
2
31
I2CCLK / MSCK / DRQ1 / INT6 / PIO0
PIO9 / ENRX0 / CTS0
3
30
I2CDAT / MISO / DRQ0 / INT5 / PIO1
PIO10 / RTR0 / RTS0
4
29
A2 / PCS6# / PIO2
PIO11 / TXD1
5
28
A1 / PCS5# / TMRIN1 / TMROUT1 / PIO3
PIO12 / INT3 / RXD1
6
IPC@CHIP
27
A0 / PCS1# / TMRIN0 / PIO4
PIO13 / INT0 / TMROUT0
7
26
RTS1# / MOSI / PCS3# / INT4 / PIO5
AD0
8
25
CTS1# / MEN / PCS2# / INT2 / INTA# / PIO6
AD1
9
24
ALE / PCS0#
AD2
10
23
WR#
AD3
11
22
RD#
AD4
12
21
TPRX- (SC02, SC12 only)
AD5
13
20
TPRX+ (SC02, SC12 only)
AD6
14
19
TPTX- (SC02, SC12 only)
AD7
15
18
TPTX+ (SC02, SC12 only)
GND
16
17
RESET# / NMI / LINK LED
