Date: November 23, 1999 Sheet 1 of 1
Size Document Number REV
A3 (C) 1995 - 1999 SC12APL3 01
Title
IPC@CHIP SC12 PIN17-Link&Traffic LED separat
Garbenheimer Strasse 38
Germany - 35578 Wetzlar
IPC GmbH
VCC VCC
470E 470E
Traffic LED Link LED
VCCVCC
* CAP
o
?N400A
DC Power supply
Main
Supply
@CHIP
17
5VDC
32
Vcc
1K
9
10
8
U1C
74HCT132
4
5
6
U1B
74HCT132
1
2
3
U1A
74HCT132
12
13
11
U1D
74HCT132
100K
10K
10uF
ZPD2V4
GND
0,8V = RES active
1,2V = NMI active
16
Gez. : IB 16.11.99
Gepr.: JW 15.11.99
