Display Contents Description
“MIC ACTIVATION”
BOTH MIKES
ENABLED:
• input /PTT1 (Pin P1-17) activates
transmission from microphone path 1 and 2
• input /PTT2 (Pin J1-5) activates
transmission from microphone path 2 and
path 1
• input /IC (Pin P1-7) activates intercom from
microphone path 1 and 2
BOTH MIKES
DISABLED:
• input /PTT1 (Pin P1-17) activates
transmission only from microphone path 1
• input /PTT2 (Pin J1-5) activates
transmission only from microphone path 2
• input /IC (Pin P1-7) activates intercom only
from microphone path 1
“OUTPUTS”
HDPH 1
ENABLED - audio available on headphone 1
output (Pins P1-2/P1-3)
HDPH 1
DISABLED - no audio available on headphone
1 output.
HDPH 2
ENABLED - audio is available on headphone 2
output (Pins P1-20/P1-22), speaker not available.
HDPH 2
DISABLED – no audio available on headphone
2 output, speaker not available.
SPEAKER
ENABLED - audio is available on speaker
(Pins P1-1/P1-14), headphone 2 not available
NONE
- no audio on headphone 2 output or speaker
output.
Note:
1 Menu available on primary controller.
2 Displayed only if MIKE_SW input (Pin J1-24)
has Inactive state.
