External testing, high active
In the case of devices with a separate test input, this is used instead of the power switch-off.
Wake-up signal for radio safety edge
Radio safety edges are inactive while the door is still. To activate the safety edge, the wake-up signal must be used and connected
to the safety edge. The wake-up signal may cause a time delay in the movement.
Door position
Various door positions can be communicated via the relay.
Door in motion
The output function "Door in motion" is activated during movement.
Outdoor light
The relay is active when the door is in motion and when the advance warning time is active. A switch-off delay can be set via
P.014: 0 – 600 s.
Warning light
The relay is active when the door is in motion and when the advance warning time is active.
Fault indication
Collective output of active error messages. Enables errors from this control unit to be displayed through an output relay in a con-
trol centre.
Locking the door
Is used to activate a locking mechanism (e.g. to close an electric door bolt). Relay is active when the door is in motion.
Locking the wicket door
Is used to activate a locking mechanism (e.g. to close an electric bolt). Relay is active except in the CLOSE limit position.
Stop light
Is used to activate a stop light. The function can also be used as two-way traffic control. The following parameters are enabled for
stop light control via P.892:1.
P. Description
01A Clearance time for switching green
01B Clearance time for red
5x4 Selection inside/outside
27
