Becker BDC-i440R - Door Profiles Configuration

Door profiles
Through the selection of a door profile in the parameter P.991, the functions of the inputs and outputs and parameters are preset
to suit a certain type of door. The values specified in the door profiles may therefore differ from the factory default settings of the
door profile 0 (P.991: 0) in the overview of parameters, in the description and on the connection and layout plan. The applicable
connecting diagrams and parameters must be observed. Application-specific profiles can be selected with P.992.
P.991:0 mechanical limit switching (Becker-Antriebe GmbH)
P.991:1 mechanical limit switching (Becker-Antriebe GmbH)
P.991:2 absolute value encoder (Becker-Antriebe GmbH)
P.992:1 two-way traffic control with M1 expansion board
P.992:2 two-way traffic control with M2 expansion board
P.991:0 mechanical limit switching (Becker-Antriebe GmbH)
Parameter Input Function
Terminals P.4E0 SE 1 Optoelectronic safety edge or electric safety edge
(specified at the initial operation stage)
P.4F0: 3.00 SE 2 Wicket door resistor 8k2 ohm
P.510: 10.00 FE 1 Slack rope NC
P.520: 22.00 FE 2 Light barrier 1
P.530: 13.00 FE 3 Drive command STOP
P.540: 12.00 FE 4 Drive command CLOSE
P.550: 11.02 FE 5 Drive command OPEN
P.560: 8.00 FE 6 Pre-limit switch (VES)
P.570*: 6.00 FE 7 OPEN limit position
P.580*: 7.00 FE 8 CLOSE limit position
*
)
The function inputs FE7 and FE8 cannot be changed if mechanical limit switches are used.
P.991:1 mechanical limit switching (Becker-Antriebe GmbH)
Parameter Input Function
Terminals P.4E0 SE 1 Optoelectronic safety edge or electric safety edge
(specified at the initial operation stage)
P.4F0: 3.00 SE 2 Wicket door resistor 8k2 ohm
P.510: 10.00 FE 1 Slack rope NC
P.520: 22.00 FE 2 Light barrier 1
P.530: 17.01 FE 3 Selection switch automatic reclosing
P.540: 11.02 FE 4 Drive command OPEN
P.550: 14.02 FE 5 Drive command sequence OPEN / STOP / CLOSE
P.560: 8.00 FE 6 Pre-limit switch (VES)
P.570*: 6.00 FE 7 OPEN limit position
P.580*: 7.00 FE 8 CLOSE limit position
*
)
The function inputs FE7 and FE8 cannot be changed if mechanical limit switches are used.
