General
These tubular drives are high-quality products with the following features:
• Optimised for roller shutter operation
• Can be used for the second escape route when using the optional roller shutter escape sets with automatic limit position res-
toration, roller shutter escape crank sets and S60 roller shutter escape drive adapter sets.
• Automatic detection of limit positions thanks to intelligent electronic system with stop systems
∙ Secure anti-lifting device
∙ Slight pressure applied to the roller shutter curtain makes it difficult to raise or reach under it
∙ Suitable for rigid aluminium, steel and wooden profiles
• Obstruction detection in downwards direction when using suspension springs and anti-lifting device
• Blockage detection in the up direction (e.g., end strip frozen to the window sill)
• The limit positions do not have to be reset: Changes in the shading solution are accommodated automatically when using stop
systems.
• Drive puts the roller shutter curtain under low tensile load
• Soft upper stop
• Several drives can be operated in parallel
• Compatible with existing drives with electronic limit switching (4-core connecting cable)
• Compatible with the comprehensive range of the drive manufacturer’s control units
Please observe these Assembly and Operating Instructions when installing and setting up the equipment.
The date of manufacture comes from the first four digits of the serial number.
The numbers 1 and 2 indicate the year and the numbers 3 and 4 indicate the calendar week.
Example: 34th calendar week in 2020
Ser. No.: 2034XXXXX
Explanation of pictograms
CAUTION
CAUTION indicates a hazardous situation which, if not avoided, could
result in injury.
ATTENTION
ATTENTION indicates measures that must be taken to avoid damage to
property.
Denotes user tips and other useful information.
Warranty
Structural modifications and incorrect installation which are not in accordance with these and our other instructions can result in
serious injuries, e.g., crushing of limbs. Therefore, structural modifications may only be carried out with our prior approval and
strictly in accordance with our instructions, particularly the information contained in these Assembly and Operating Instructions.
Any further processing of the products which does not comply with their intended use is not permitted.
The end product manufacturer and fitter have to ensure that all the relevant current statutory, official and, in particular, EMC regu-
lations are adhered to during utilisation of our products, especially with regard to end product manufacture, installation and cus-
tomer advice.
3-en
