Becker R30-17 - Wiring Diagrams; Single Switch;Button Control Wiring

Sample wiring diagrams
The assignment of the black and brown wires according to the direction of travel is de-
pendant on how the drive is installed (mounted to the right or to the left).
Controlling one/several drive(s) via a single switch/button
Controls
black br
own
blue
green/yellow
C
ontrols
23-en
