Beckett CF375 - Replacement Parts Catalog

19
CF375 Burner Manual
Item Name/Description Part Number
1 Air Tube See Figure 3
2 Spline Nut 3666
3 Adjusting plate assembly 5721
4 Blocking Oil Solenoid Valve 2182602U
5 Igniter 51771U
6 Control Specify
7 Air Band 3492
8 Air Shutter 3709
9 Fuel Pump See Table 2
10 Fuel lines Specify Lengths
11 Head Assembly:
KY (Tube A)
KZ (Tube B)
5913
51820
12 Electrode Assembly Refer to Figure 6
13 Nozzle Line Assembly Refer to Figure 6
14 Motor - 1/7 PSC 21805U
15 Blower Wheel 21837U
16 Coupling 2433
17 Flange Kit (not shown) 5432 - non-pressure fi red
51311 - pressure fi red
Note: CF500/800 shown, CF375 is similar
Replacement Parts
for best performance specify genuine Beckett replacement parts
Section: Replacement Parts
1
2
3
10
9
8
4
5
6
7
12
11
13
15
14
16
