Installation
3.2 Installation of the PC in the control cabinet
The C6030-0060 Industrial PC is designed for mounting in control cabinets for machine and plant
engineering applications. The ambient conditions specified for operation must be observed (see chapter
Technical Data).
3.2.1 Flexible mounting mechanism
The Industrial PC is provided with a flexible mounting mechanism for the free alignment of the connecting
area (see also chapter Assembly dimensions) according to the order option:
Order option Version
none Provided with mounting sheet for rear wall installation
C9900-M668 Provided with mounting sheet for side wall installation, instead of sheet at the rear wall
C9900-M669 Only mounting sheet for side wall installation
The mounting sheets are fastened at the Industrial PC using Torx screws of size TX10.
3.2.2 Preparation of the control cabinet
The holes for the fixing bolts have to be provided in the control cabinet according to the dimensions of the
PC (see chapter Assembly dimensions).
Circulation of air
Note
When the unit is installed in an enclosure, adequate space for ventilation and for
opening the PC must be provided.
The clearance above and below the housing must be at least 5 cm and laterally at least
2 cm in order to ensure adequate ventilation of the PC.
Avoid extreme environmental conditions
Attention
Extreme environmental conditions should be avoided as far as possible. Protect the PC
from dust, moisture and heat.
The ventilation slots of the PC must not be covered.
16 C6030-0060
