Operating/Configuration
CX50x054 Version: 1.9
Intel HD Audio Controller
Option for activating the internal audio controller. The function is disabled since currently no associated
extension is implemented.
USB Client Routing
Option for configuring the second USB port with USB client functionality.
SDIO/MMC Controller
Option for activating/deactivating the SDIO / MMC controller. In general the CX50x0 units are not equipped
with the required hardware. The function is therefore disabled.
Onboard Lan Controller
The two Gigabit LAN ports are always enabled.
Console Redirect
Option for redirecting the boot process output to the serial interface. If the function is enabled the
communication parameters in the locked menus can be set.
Serial Port Mode
Option for setting the baud rate, number of bits, parity and stop bit.
After Boot
The console can remain active after the boot process. This function is only supported by a small number of
operating systems.
Flow Control Signals
Option for activating or deactivating hardware flow control.
4.3.4.3 SuperIO Device
This menu is used for configuring the USB and audio interfaces.
Phoenix - AwardBIOS CMOS Setup Utility
SuperIO Device
Onboard Serial Port 1 [3F8/IRQ4] Item Help
Onboard Serial Port 2 [2F8/IRQ3]
UART Mode Select [Normal]
RxD, TxD Active Hi, Lo
IR Transmission Delay Enabled
UR2 Duplex Mode Half
Use IR Pins IR-Rx2Tx2
↑ ↓ → ← :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit [}52] F1:Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
