Commissioning/Configuration
5.1.2.5 SATA Configuration
Aptio Setup Utility - Copyright (C) American Megatrends, Inc.
SATA Configuration
Serial-ATA (SATA) [Enabled]
SATA Test Mode [Disabled]
SATA Speed Support [Gen2]
SATA ODD Port [No ODD]
SATA Mode [AHCI]
Serial ATA Port 0 [Enabled]
Hot Plug [Disabled]
Serial ATA Port 1 [Enabled]
Hot Plug [Disabled]
SATA Port0 → ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Options
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Quit
Not Present
SATA Port1
Not Present
Version 2.17.1246. Copyright (C) 2014 American Megatrends, Inc.
Serial-ATA (SATA)
Options: Enabled / Disabled
Activates or deactivates the current sequential ATA controller. All devices connected to the SATA controller
are activated or deactivated.
SATA Test Mode
Options: Enabled / Disabled
Activates or deactivates testing of the SATA mode.
SATA Speed Support
Options: Gen1 / Gen2
Sets the SATA controller to SATA I (1.2 Gbps) or SATA II (2.4 Gbps).
SATA ODD Port
Options: No Odd / Odd Port 1 / Odd Port 2
This is set if an optical drive is connected to port 1 or port 2.
SATA Mode
Options: IDE Mode / AHCI Mode
Defines the SATA mode: IDE, AHCI
IDE: Select this mode to operate a SATA device in IDE mode.
AHCI: Select this mode if you use a 64-bit operating system.
Serial ATA Port X
Options: Empty
Shows the modes of the SATA port.
Empty: No SATA port is supported.
CX51x054 Version: 1.6
