Commissioning
EL34xx 133Version: 1.5
Predefined PDO Assignment
The "Predefined PDO Assignment" enables a simplified selection of the process data. The desired function is
selected on the lower part of the "Process Data" tab. As a result, all necessary PDOs are automatically
activated and the unnecessary PDOs are deactivated.
The following PDO assignments are available:
EL3423
Name SM2, PDO assignment SM3, PDO assignment
Default - 0x1A00 (L1 Status)
0x1A03 (L1 Energy)
0x1A0A (L2 Status)
0x1A0D (L2 Energy)
0x1A14 (L3 Status)
0x1A17 (L3 Energy)
0x1A1E (Total Total Status)
0x1A21 (Total Total Active)
0x1A22 (Total Total Apparent)
0x1A23 (Total Total Reactive)
Default + Statistics - 0x1A00 (L1 Status)
0x1A03 (L1 Energy)
0x1A06 (L1 Statistic Voltage)
0x1A0A (L2 Status)
0x1A0D (L2 Energy)
0x1A10 (L2 Statistic Voltage)
0x1A14 (L3 Status)
0x1A17 (L3 Energy)
0x1A1A (L3 Statistic Voltage)
0x1A1E (Total Total Status)
0x1A20 (Total Total Advanced)
0x1A26 (Total Total Statistic Power)
0x1A27 (Total Total Statistic PQF)
0x1A28 (Total Total Interval Energy)
