Commissioning
EL34xx134 Version: 1.5
EL3443
Name SM2, PDO assignment SM3, PDO assignment
Default - 0x1A00 (L1 Status)
0x1A01 (L1 Basic)
0x1A02 (L1 Power)
0x1A04 (L1 Timing)
0x1A0A (L2 Status)
0x1A0B (L2 Basic)
0x1A0C (L2 Power)
0x1A0E (L2 Timing)
0x1A14 (L3 Status)
0x1A15 (L3 Basic)
0x1A16 (L3 Power)
0x1A18 (L3 Timing)
0x1A1E (Total Total Status)
0x1A1F (Total Total Basic)
0x1A21 (Total Total Active)
0x1A24 (Total Total L-L Voltage)
Default + Variant 0x1600 (Total Outputs Device) 0x1A00 (L1 Status)
0x1A01 (L1 Basic)
0x1A02 (L1 Power)
0x1A04 (L1 Timing)
0x1A0A (L2 Status)
0x1A0B (L2 Basic)
0x1A0C (L2 Power)
0x1A0E (L2 Timing)
0x1A14 (L3 Status)
0x1A15 (L3 Basic)
0x1A16 (L3 Power)
0x1A18 (L3 Timing))
0x1A1E (Total Total Status)
0x1A1F (Total Total Basic)
0x1A25 (Total Variant Value In)
Advanced - 0x1A00 (L1 Status)
0x1A01 (L1 Basic)
0x1A02 (L1 Power)
0x1A03 (L1 Energy)
0x1A04 (L1 Timing)
0x1A0A (L2 Status)
0x1A0B (L2 Basic)
0x1A0C (L2 Power)
0x1A0D (L2 Energy)
0x1A0E (L2 Timing)
0x1A14 (L3 Status)
0x1A15 (L3 Basic)
0x1A16 (L3 Power)
0x1A17 (L3 Energy)
0x1A18 (L3 Timing))
0x1A1E (Total Total Status)
0x1A1F (Total Total Basic)
0x1A20 (Total Total Advanced)
0x1A21 (Total Total Active)
Total Only 0x1600 (Total Outputs Device) 0x1A00 (L1 Status)
0x1A0A (L2 Status)
0x1A14 (L3 Status)
0x1A1E (Total Total Status)
0x1A1F (Total Total Basic)
0x1A20 (Total Total Advanced)
0x1A21 (Total Total Active)
0x1A22 (Total Total Apparent)
0x1A23 (Total Total Reactive)
0x1A24 (Total Total L-L Voltage)
0x1A25 (Total Variant Value In)
