Beckhoff EL34 Series User Manual

Commissioning
EL34xx 135Version: 1.5
EL3443
Name SM2, PDO assignment SM3, PDO assignment
0x1A26 (Total Total Statistic Power)
0x1A27 (Total Total Statistic PQF)
0x1A28 (Total Total Interval Energy)
Classic 0x1600 (Total Outputs Device) 0x1A00 (L1 Status)
0x1A09 (L1 Classic)
0x1A0A (L2 Status)
0x1A13 (L2 Classic)
0x1A14 (L3 Status)
0x1A1D (L3 Classic)
0x1A1E (Total Total Status)
Single Phase 0x1600 (Total Outputs Device)
0x1601 (Total Interval)
0x1A00 (L1 Status)
0x1A01 (L1 Basic)
0x1A02 (L1 Power)
0x1A03 (L1 Energy)
0x1A04 (L1 Timing)
0x1A06 (L1 Statistic Voltage)
0x1A1E (Total Total Status)
0x1A1F (Total Total Basic)
0x1A25 (Total Variant Value In)
0x1A28 (Total Total Interval Energy)
