Beckhoff EL34 Series User Manual

Commissioning
EL34xx136 Version: 1.5
EL3453
Name SM2, PDO assignment SM3, PDO assignment
Default - 0x1A00 (L1 Status)
0x1A01 (L1 Basic)
0x1A02 (L1 Power)
0x1A0C (L2 Status)
0x1A0D (L2 Basic)
0x1A0E (L2 Power)
0x1A18 (L3 Status)
0x1A19 (L3 Basic)
0x1A1A (L3 Power)
0x1A24 (Total Status)
0x1A25 (Total Basic)
Default + Variant 0x1600 (Total Variant Value Out) 0x1A00 (L1 Status)
0x1A01 (L1 Basic)
0x1A02 (L1 Power)
0x1A0C (L2 Status)
0x1A0D (L2 Basic)
0x1A0E (L2 Power)
0x1A18 (L3 Status)
0x1A19 (L3 Basic)
0x1A1A (L3 Power)
0x1A24 (Total Status)
0x1A25 (Total Basic)
0x1A2E (Total Variant Value In)
Advanced - 0x1A00 (L1 Status)
0x1A01 (L1 Basic)
0x1A02 (L1 Power)
0x1A07 (L1 Advanced)
0x1A0C (L2 Status)
0x1A0D (L2 Basic)
0x1A0E (L2 Power)
0x1A13 (L2 Advanced)
0x1A18 (L3 Status)
0x1A19 (L3 Basic)
0x1A1A (L3 Power)
0x1A1F (L3 Advanced)
0x1A24 (Total Status)
0x1A25 (Total Basic)
0x1A26 (Total Advanced)
Total Only 0x1600 (Total Variant Value Out) 0x1A00 (L1 Status)
0x1A0C (L2 Status)
0x1A18 (L3 Status)
0x1A24(Total Status)
0x1A25 (Total Basic)
0x1A26(Total Advanced)
0x1A27(Active)
0x1A29 (Total Apparent)
0x1A2B (Total Reactive)
0x1A2E (Total Variant Value In)
Classic 0x1600 (Total Variant Value Out) 0x1A00 (L1 Status)
0x1A0B (L1 Classic)
0x1A0C (L2 Status)
0x1A17 (L2 Classic)
0x1A18 (L3 Status)
0x1A23 (L3 Classic)
0x1A2E (Total Variant Value In)
Single Phase 0x1600 (Total Outputs Device)
0x1601 (Total Interval)
0x1A00 (L1 Status)
0x1A01 (L1 Basic)
0x1A02 (L1 Power)
0x1A06 (L1 Timing)
