Beckhoff EL34 Series User Manual

Commissioning
EL34xx176 Version: 1.5
Index 1A2C Total TxPDO-Map Interval Energy Reduced
Index (hex) Name Meaning Data type Flags Default
1A2C:0 Total TxPDO-Map In-
terval Energy Re-
duced
PDO Mapping TxPDO 36 UINT8 RO 0x05 (5
dez
)
1A2C:01 SubIndex 001 1. PDO Mapping entry (align) UINT32 RO 0x0000:00, 15
1A2C:02 SubIndex 002 2. PDO Mapping entry (object 0xF615 (PMX Total In-
terval Energy Reduced), entry 0x10 (TxPDO Toggle))
UINT32 RO 0xF615:10, 1
1A2C:03 SubIndex 003 3. PDO Mapping entry (object 0xF615 (PMX Total In-
terval Energy Reduced), entry 0x11 (Active Energy))
UINT32 RO 0xF615:11, 32
1A2C:04 SubIndex 004 4. PDO Mapping entry (object 0xF615 (PMX Total In-
terval Energy Reduced), entry 0x12 (Apparent En-
ergy))
UINT32 RO 0xF615:12, 32
1A2C:05 SubIndex 005 5. PDO Mapping entry (object 0xF615 (PMX Total In-
terval Energy Reduced), entry 0x13 (reactive En-
ergy))
UINT32 RO 0xF615:13, 32
Index 1C00 Sync manager type
Index (hex) Name Meaning Data type Flags Default
1C00:0 Sync manager type Length of this object UINT8 RO 0x04 (4
dec
)
1C00:01 SubIndex 001 Sync-Manager Type Channel 1: Mailbox Write UINT8 RW 0x01 (1
dec
)
1C00:02 SubIndex 002 Sync-Manager Type Channel 2: Mailbox Read UINT8 RW 0x02 (2
dec
)
1C00:03 SubIndex 003 Sync-Manager Type Channel 3: Process Data Write
(Outputs)
UINT8 RW 0x03 (3
dec
)
1C00:04 SubIndex 004 Sync-Manager Type Channel 4: Process Data Read
(Inputs)
UINT8 RW 0x04 (4
dec
)
Index 1C12 RxPDO assign
Index (hex) Name Meaning Data type Flags Default
1C12:0 RxPDO assign PDO Assign Outputs UINT8 RW 0x01 (1
dec
)
1C12:01 SubIndex 001 1. allocated RxPDO (contains the index of the associ-
ated RxPDO mapping object)
UINT16 RW 0x1601 (5633
dec
)
