Commissioning

EL34xx 175Version: 1.5

Index 1A28 Total TxPDO-Map Total Interval Energy

Index (hex) Name Meaning Data type Flags Default

1A28:0 Total TxPDO-Map To-

tal Interval Energy

PDO Mapping TxPDO 41 UINT8 RO 0x0B (11

dec

)

1A28:01 SubIndex 001 1. PDO Mapping entry (15 bits align) UINT32 RO 0x0000:00, 15

1A28:02 SubIndex 002 2. PDO Mapping entry (object 0xF60D (PMX Total In-

terval Energy), entry 0x10 (TxPDO Toggle))

UINT32 RO 0xF60D:10, 1

1A28:03 SubIndex 003 3. PDO Mapping entry (object 0xF60D (PMX Total In-

terval Energy), entry 0x11 (Active Energy))

UINT32 RO 0xF60D:11, 32

1A28:04 SubIndex 004 4. PDO Mapping entry (object 0xF60D (PMX Total In-

terval Energy), entry 0x12 (Active Energy Positive))

UINT32 RO 0xF60D:12, 32

1A28:05 SubIndex 005 5. PDO Mapping entry (object 0xF60D (PMX Total In-

terval Energy), entry 0x13 (Active Energy Negative))

UINT32 RO 0xF60D:13, 32

1A28:06 SubIndex 006 6. PDO Mapping entry (object 0xF60D (PMX Total In-

terval Energy), entry 0x14 (Apparent Energy))

UINT32 RO 0xF60D:14, 32

1A28:07 SubIndex 007 7. PDO Mapping entry (object 0xF60D (PMX Total In-

terval Energy), entry 0x15 (Apparent Energy Posi-

tive))

UINT32 RO 0xF60D:15, 32

1A28:08 SubIndex 008 8. PDO Mapping entry (object 0xF60D (PMX Total In-

terval Energy), entry 0x16 (Apparent Energy Nega-

tive))

UINT32 RO 0xF60D:16, 32

1A28:09 SubIndex 009 9. PDO Mapping entry (object 0xF60D (PMX Total In-

terval Energy), entry 0x17 (Reactive Energy))

UINT32 RO 0xF60D:17, 32

1A28:0A SubIndex 010 10. PDO Mapping entry (object 0xF60D (PMX Total

Interval Energy), entry 0x18 (Reactive Energy Posi-

tive))

UINT32 RO 0xF60D:18, 32

1A28:0B SubIndex 011 11. PDO Mapping entry (object 0xF60D (PMX Total

Interval Energy), entry 0x19 (Reactive Energy Nega-

tive))

UINT32 RO 0xF60D:19, 32

Index 1A29 Total TxPDO-Map Active Reduced

Index (hex) Name Meaning Data type Flags Default

1A29:0 Total TxPDO-Map Ac-

tive Reduced

PDO Mapping TxPDO 35 UINT8 RO 0x02 (2

dec

)

1A29:01 SubIndex 001 1. PDO Mapping entry (Alignet)) UINT32 RO 0x0000:00, 32

1A29:02 SubIndex 002 2. PDO Mapping entry (object 0xF612 (PMX Total

Apparent), entry 0x12 (Active Reduced))

UINT32 RO 0xF612:12, 64

Index 1A2A Total TxPDO-Map Apparent Reduced

Index (hex) Name Meaning Data type Flags Default

1A2A:0 Total TxPDO-Map Ap-

parent Reduced

PDO Mapping TxPDO 35 UINT8 RO 0x02 (2

dec

)

1A2A:01 SubIndex 001 1. PDO Mapping entry (object 0xF613 (PMX Total

Apparent Reduced), entry 0x11 (Apparent Power))

UINT32 RO 0xF613:11, 32

1A2A:02 SubIndex 002 2. . PDO Mapping entry (object 0xF613 (PMX Total

Apparent Reduced), entry 0x12 (Apparent Energy))

UINT32 RO 0xF613:12, 64

Index 1A2B Total TxPDO-Map Reactive Reduced

Index (hex) Name Meaning Data type Flags Default

1A2B:0 Total TxPDO-Map

Reactive Reduced

PDO Mapping TxPDO 36 UINT8 RO 0x02 (2

dec

)

1A2B:01 SubIndex 001 1. PDO Mapping entry (object 0xF614 (PMX Total

Reactive Reduced), entry 0x11 (Reactive Power))

UINT32 RO 0xF614:11, 32

1A2B:02 SubIndex 002 2. PDO Mapping entry (object 0xF614 (PMX Total

Reactive Reduced), entry 0x12 (Reactive Energy))

UINT32 RO 0xF614:12, 64
