Index 1A22 Total TxPDO-Map Total Apparent
Index (hex) Name Meaning Data type Flags Default
1A22:0 Total TxPDO-Map To-
tal Apparent
PDO Mapping TxPDO 35 UINT8 RO 0x04 (4
dec
)
1A22:01 SubIndex 001 1. PDO Mapping entry (32 bits align) UINT32 RO 0x0000:00, 32
1A22:02 SubIndex 002 2. PDO Mapping entry (object 0xF605 (PMX Total
Apparent), entry 0x12 (Apparent Energy))
UINT32 RO 0xF605:12, 64
1A22:03 SubIndex 003 3. PDO Mapping entry (object 0xF605 (PMX Total
Apparent), entry 0x13 (Apparent Positive Energy))
UINT32 RO 0xF605:13, 64
1A22:04 SubIndex 004 4. PDO Mapping entry (object 0xF605 (PMX Total
Apparent), entry 0x14 (Apparent Negative Energy))
UINT32 RO 0xF605:14, 64
Index 1A23 Total TxPDO-Map Total Reactive
Index (hex) Name Meaning Data type Flags Default
1A23:0 Total TxPDO-Map To-
tal Reactive
PDO Mapping TxPDO 36 UINT8 RO 0x04 (4
dec
)
1A23:01 SubIndex 001 1. PDO Mapping entry (32 bits align) UINT32 RO 0x0000:00, 32
1A23:02 SubIndex 002 2. PDO Mapping entry (object 0xF607 (PMX Total
Reactive), entry 0x12 (Reactive Energy))
UINT32 RO 0xF607:12, 64
1A23:03 SubIndex 003 3. PDO Mapping entry (object 0xF607 (PMX Total
Reactive), entry 0x13 (Reactive Positive Energy))
UINT32 RO 0xF607:13, 64
1A23:04 SubIndex 004 4. PDO Mapping entry (object 0xF607 (PMX Total
Reactive), entry 0x14 (Reactive Negative Energy))
UINT32 RO 0xF607:14, 64
Index 1A26 Total TxPDO-Map Total Statistic Power
Index (hex) Name Meaning Data type Flags Default
1A26:0 Total TxPDO-Map To-
tal Statistic Power
PDO Mapping TxPDO 39 UINT8 RO 0x09 (9
dec
)
1A26:01 SubIndex 001 1. PDO Mapping entry (object 0xF60B (PMX Total
Statistic Power), entry 0x11 (Active Power Avg))
UINT32 RO 0xF60B:11, 32
1A26:02 SubIndex 002 2. PDO Mapping entry (object 0xF60B (PMX Total
Statistic Power), entry 0x12 (Active Power Min))
UINT32 RO 0xF60B:12, 32
1A26:03 SubIndex 003 3. PDO Mapping entry (object 0xF60B (PMX Total
Statistic Power), entry 0x13 (Active Power Max))
UINT32 RO 0xF60B:13, 32
1A26:04 SubIndex 004 4. PDO Mapping entry (object 0xF60B (PMX Total
Statistic Power), entry 0x14 (Apparent Power Avg))
UINT32 RO 0xF60B:14, 32
1A26:05 SubIndex 005 5. PDO Mapping entry (object 0xF60B (PMX Total
Statistic Power), entry 0x15 (Apparent Power Min))
UINT32 RO 0xF60B:15, 32
1A26:06 SubIndex 006 6. PDO Mapping entry (object 0xF60B (PMX Total
Statistic Power), entry 0x16 (Apparent Power Max))
UINT32 RO 0xF60B:16, 32
1A26:07 SubIndex 007 7. PDO Mapping entry (object 0xF60B (PMX Total
Statistic Power), entry 0x17 (Reactive Power Avg))
UINT32 RO 0xF60B:17, 32
1A26:08 SubIndex 008 8. PDO Mapping entry (object 0xF60B (PMX Total
Statistic Power), entry 0x18 (Reactive Power Min))
UINT32 RO 0xF60B:18, 32
1A26:09 SubIndex 009 9. PDO Mapping entry (object 0xF60B (PMX Total
Statistic Power), entry 0x19 (Reactive Power Max))
UINT32 RO 0xF60B:19, 32
Index 1A27 Total TxPDO-Map Total Statistic PQF
Index (hex) Name Meaning Data type Flags Default
1A27:0 Total TxPDO-Map To-
tal Statistic PQF
PDO Mapping TxPDO 40 UINT8 RO 0x03 (3
dec
)
1A27:01 SubIndex 001 1. PDO Mapping entry (object 0xF60C (PMX Total
Statistic PQF), entry 0x11 (PQF Avg))
UINT32 RO 0xF60C:11, 32
1A27:02 SubIndex 002 2. PDO Mapping entry (object 0xF60C (PMX Total
Statistic PQF), entry 0x12 (PQF Min))
UINT32 RO 0xF60C:12, 32
1A27:03 SubIndex 003 3. PDO Mapping entry (object 0xF60C (PMX Total
Statistic PQF), entry 0x13 (PQF Max))
UINT32 RO 0xF60C:13, 32
