Commissioning
EL34xx 173Version: 1.5
Index 1A1E Total TxPDO-Map Total Status
Index (hex) Name Meaning Data type Flags Default
1A1E:0 Total TxPDO-Map To-
tal Status
PDO Mapping TxPDO 31 UINT8 RO 0x10 (16
dec
)
1A1E:01 SubIndex 001 1. PDO Mapping entry (object 0xF600 (PMX Total
Status), entry 0x01 (System State))
UINT32 RO 0xF600:01, 1
1A1E:02 SubIndex 002 2. PDO Mapping entry (object 0xF600 (PMX Total
Status), entry 0x02 (Grid Direction))
UINT32 RO 0xF600:02, 1
1A1E:03 SubIndex 003 3. PDO Mapping entry (object 0xF600 (PMX Total
Status), entry 0x03 (Frequency Guard Warning))
UINT32 RO 0xF600:03, 1
1A1E:04 SubIndex 004 4. PDO Mapping entry (object 0xF600 (PMX Total
Status), entry 0x04 (Frequency Guard Error))
UINT32 RO 0xF600:04, 1
1A1E:05 SubIndex 005 5. PDO Mapping entry (object 0xF600 (PMX Total
Status), entry 0x05 (Neutral Current Guard Warning))
UINT32 RO 0xF600:05, 1
1A1E:06 SubIndex 006 6. PDO Mapping entry (object 0xF600 (PMX Total
Status), entry 0x06 (Neutral Current Guard Error))
UINT32 RO 0xF600:06, 1
1A1E:07 SubIndex 007 7. PDO Mapping entry (object 0xF600 (PMX Total
Status), entry 0x07 (Active Power Guard Warning))
UINT32 RO 0xF600:07, 1
1A1E:08 SubIndex 008 8. PDO Mapping entry (object 0xF600 (PMX Total
Status), entry 0x08 (Active Power Guard Error))
UINT32 RO 0xF600:08, 1
1A1E:09 SubIndex 009 9. PDO Mapping entry (object 0xF600 (PMX Total
Status), entry 0x09 (Apparent Power Guard Warn-
ing))
UINT32 RO 0xF600:09, 1
1A1E:0A SubIndex 010 10. PDO Mapping entry (object 0xF600 (PMX Total
Status), entry 0x0A (Apparent Power Guard Error))
UINT32 RO 0xF600:0A, 1
1A1E:0B SubIndex 011 11. PDO Mapping entry (object 0xF600 (PMX Total
Status), entry 0x0B (Power Quality Guard Warning))
UINT32 RO 0xF600:0B, 1
1A1E:0C SubIndex 012 12. PDO Mapping entry (object 0xF600 (PMX Total
Status), entry 0x0C (Power Quality Guard Error))
UINT32 RO 0xF600:0C, 1
1A1E:0D SubIndex 013 13. PDO Mapping entry (2 bits align) UINT32 RO 0x0000:00, 2
1A1E:0E SubIndex 014 14. PDO Mapping entry (object 0xF600 (PMX Total
Status), entry 0x0F (TxPDO State))
UINT32 RO 0xF600:0F, 1
1A1E:0F SubIndex 015 15. PDO Mapping entry (object 0xF600 (PMX Total
Status), entry 0x10 (TxPDO Toggle))
UINT32 RO 0xF600:10, 1
1A1E:10 SubIndex 016 16. PDO Mapping entry (object 0xF600 (PMX Total
Status), entry 0x11 (Power Quality Factor))
UINT32 RO 0xF600:11, 32
Index 1A20 Total TxPDO-Map Total Advanced
Index (hex) Name Meaning Data type Flags Default
1A20:0 Total TxPDO-Map To-
tal Advanced
PDO Mapping TxPDO 33 UINT8 RO 0x03 (3
dec
)
1A20:01 SubIndex 001 1. PDO Mapping entry (object 0xF602 (PMX Total
Advanced), entry 0x01 (Unbalance Guard Warning))
UINT32 RO 0xF602:01, 1
1A20:02 SubIndex 002 2. PDO Mapping entry (object 0xF602 (PMX Total
Advanced), entry 0x02 (Unbalance Guard Error))
UINT32 RO 0xF602:02, 1
1A20:03 SubIndex 003 3. PDO Mapping entry (14 bits align) UINT32 RO 0x0000:00, 14
Index 1A21 Total TxPDO-Map Total Active
Index (hex) Name Meaning Data type Flags Default
1A21:0 Total TxPDO-Map To-
tal Active
PDO Mapping TxPDO 34 UINT8 RO 0x04 (4
dec
)
1A21:01 SubIndex 001 1. PDO Mapping entry (32 bits align) UINT32 RO 0x0000:00, 32
1A21:02 SubIndex 002 2. PDO Mapping entry (object 0xF603 (PMX Total
Active), entry 0x12 (Active Energy))
UINT32 RO 0xF603:12, 64
1A21:03 SubIndex 003 3. PDO Mapping entry (object 0xF603 (PMX Total
Active), entry 0x13 (Active Positive Energy))
UINT32 RO 0xF603:13, 64
1A21:04 SubIndex 004 4. PDO Mapping entry (object 0xF603 (PMX Total
Active), entry 0x14 (Active Negative Energy))
UINT32 RO 0xF603:14, 64
