Commissioning
EL34xx172 Version: 1.5
**) for L1, n = 0; L2, n = 1; L3, n = 2)
Index 1App TxPDO-Map Statistic Current (for L1, pp = 07; L2, pp = 11; L3, pp = 1B)
Index (hex) Name Meaning Data type Flags Default
1App:0 L1 TxPDO-Map
Statistic Current
PDO Mapping TxPDO 8 UINT8 RO 0x03 (3
dez
)
1App:01 SubIndex 001 1. PDO Mapping entry (object 0x60n9 (PMX Statistic
Current), entry 0x11 (Current Peak))
UINT32 RO 0x60n9:11, 32**
1App:02 SubIndex 002 2. PDO Mapping entry (object 0x60n9 (PMX Statistic
Current), entry 0x12 (Current RMS Minimum))
UINT32 RO 0x60n9:12, 32**
1App:03 SubIndex 003 3. PDO Mapping entry (object 0x60n9 (PMX Statistic
Current), entry 0x13 (Current RMS Maximum))
UINT32 RO 0x60n9:13, 32**
**) for L1, n = 0; L2, n = 1; L3, n = 2)
Index 1App TxPDO-Map Statistic Power (for L1, pp = 08; L2, pp = 12; L3, pp = 1C)
Index (hex) Name Meaning Data type Flags Default
1App:0 TxPDO-Map Statistic
Power
PDO Mapping TxPDO UINT8 RO 0x09 (9
dec
)
1App:01 SubIndex 001 1. PDO Mapping entry (object 0x60nA (PMX Statistic
Power), entry 0x11 (Active Power Avg))
UINT32 RO 0x60nA:11, 32**
1App:02 SubIndex 002 2. PDO Mapping entry (object 0x60nA (PMX Statistic
Power), entry 0x12 (Active Power Min))
UINT32 RO 0x60nA:12, 32**
1App:03 SubIndex 003 3. PDO Mapping entry (object 0x60nA (PMX Statistic
Power), entry 0x13 (Active Power Max))
UINT32 RO 0x60nA:13, 32**
1App:04 SubIndex 004 4. PDO Mapping entry (object 0x60nA (PMX Statistic
Power), entry 0x14 (Apparent Power Avg))
UINT32 RO 0x60nA:14, 32**
1App:05 SubIndex 005 5. PDO Mapping entry (object 0x60nA (PMX Statistic
Power), entry 0x15 (Apparent Power Max))
UINT32 RO 0x60nA:15, 32**
1App:06 SubIndex 006 6. PDO Mapping entry (object 0x60nA (PMX Statistic
Power), entry 0x16 (Reactive Power Avg))
UINT32 RO 0x60nA:16, 32**
1App:07 SubIndex 007 7. PDO Mapping entry (object 0x60nA (PMX Statistic
Power), entry 0x17 (Reactive Power Min))
UINT32 RO 0x60nA:17, 32**
1App:08 SubIndex 008 8. PDO Mapping entry (object 0x60nA (PMX Statistic
Power), entry 0x18 (Reactive Power Max))
UINT32 RO 0x60nA:18, 32**
1App:09 SubIndex 009 9. PDO Mapping entry (object 0x60nA (PMX Statistic
Power), entry 0x19 (Apparent Power Min))
UINT32 RO 0x60nA:19, 32**
**) for L1, n = 0; L2, n = 1; L3, n = 2)
