Operation and Maintenance Manual Rev: C17
A – 7: Calculations
A – 7.1: Enter Parameters
By selecting this, the controller will step you
through entering the values for Pool Volume,
whether it should use TDS for calculations,
Calcium Hardness, and Alkalinity. Once the values
have been entered, the calculated LSI & Ryzner
reading will appear in the menu and on the display.
A – 7.2: LSI Setup
Use TDS?: Selects if the controller should use
TDS for the LSI/RSI calculations.
Pool Volume: Allows you to enter the volume of
the pool.
Display RSI/LSI: Allows you to select if the
RSI/LSI information is displayed on the routine
display.
A – 8: System Configuration
Press Menu on the controller’s face panel and select
System Configuration from the menu. This will allow
you to configure the following for the system:
A – 8.1: System Info
This information menu displays the controller's
system type, serial number, and firmware version
information. From this menu you can also view
the current Ethernet network status, Modem
status, and EZConnect status. The Ethernet
network status menus display the Ethernet card’s
version information, current network
configuration, and link status.
A – 8.2: Communication
Once you have entered System Configuration,
select Communication from the menu. Under
communication, you can select from the following.
A – 8.2.1: EZConnect
(Mgr) If the current user’s access code is set,
this menu allows you to view, create and disable
EZConnect authentication codes. If the current
user’s access code is not set, this menu will only
display a notice explaining this.
A – 8.2.2: Ethernet Setup
These parameters should be set to values
provided by the network’s administrators.
Enable DHCP (Op): Enables/disables using
DHCP. If DHCP is enabled, the controller will
retrieve its IP address information from a
DHCP server on the network. If DHCP is
disabled, the IP address information must be set
manually via the remaining items listed here.
IP Address (Op): This option is only shown if
DHCP is disabled. Sets the controllers IP
address.
IP Netmask (Op): This option is only shown if
DHCP is disabled. Sets the controllers IP
netmask.
IP Default Route (Op): This option is only shown
if DHCP is disabled. Sets the controllers IP
default route/gateway.
TCP Port (Op): Sets the TCP port to listen for
connections on. Acceptable values are 1024-
1089 and 1091-65535.
DNS Server 1 (Op): Sets the IP address for the
primary DNS server. Required for email call
outs.
DNS Server 2 (Op): (Optional) Sets the IP
address for the secondary DNS server which is
only used if DNS server 1 cannot be contacted.
A – 8.2.3: SMTP Setup
EZMail Enable (Op): Only shown if EZConnect
is enabled. Enable or disable using EZConnect
to send email and text message based callouts.
SMTP Server Addr (Op): Only shown if
EZConnect or EZMail is disabled. Sets the email
SMTP server address used by alarm call out to
send email and text messages.
SMTP Server Port (Op): Only shown if
EZConnect or EZMail is disabled. Sets the email
SMTP TCP port. This value should be set to
25 unless otherwise instructed by a network
administrator.
Sender Email (Op): Only shown if EZConnect or
EZMail is disabled. Set the email address to use
for the From field in email callouts. If left
blank, an email address based off this unit's
serial number will be used.
Authentication (Op): Only shown if EZConnect
or EZMail is disabled. Enable/Disable SMTP
authentication. Many SMTP servers require
users to authenticate with a user name and
password before sending email through them.
Usually used with SSL or TLS encryption.
Auth User Name (Op): (Only shown if
Authentication is enabled) Logon user name to use
for Authorization.
Auth Password (Op): (Only shown if
Authentication is enabled) Password to use for
Authorization.
Encryption Type (Op): Only shown if
EZConnect or EZMail is disabled. Select the type
of encryption to use with the SMTP server
(SSL, TLS, or none). SSL and TLS are usually
used in combination with Authentication.
