Section G: Replacement / Maintenance Parts
Fuses
Standard Fuses
8140095
115V Unit Main Fuse
Time Lag 500mA 250V
8140086
230V Unit Main Fuse
Time Lag 250mA 250V
8140088
Relays 1-4 & 6-9 Fuse
Time Lag 3A 250V
8140092
Relay 5 Fuse
Time Lag 8A 250V
Boards
CPU / Interface Boards
2200421
BECSys7 CPU/Relay PCB
1200424
BECSys7 UI PCB
Communications Boards
2200712
BECSys Gigabit Card
Option Boards
1200494
BECSys Loop Power Board (4 power supplies for 4-
20mA inputs)
1200453
BECSys 4-20mA output board (4 channel, 440 ohm)
with 4 power supplies for 4-20mA inputs
Misc
Enclosure Parts
8060627
Enclosure Plug 0.875”
8060628
Enclosure Plug 1.125”
8520173
Single BNC cable assembly
8060736
Small watertight cord grip PG-7
M000070
BECSys7 Lid Assembly (No PCB)
Flow Cell
Round Flow Cell
1210147
Round Flow Cell
Rectangular Flow Cell
1210137
2-Sensor Rectangular Flow Cell
1210136
3-Sensor Rectangular Flow Cell
Lighted Flow Cell
2210452
Lighted Flow Cell with CP-1 Module
2210456
Lighted Flow Cell without CP-1 Module
Standard Sensors
pH Sensors
9660013
BECSys pH Sensor (30” cable) [range: 0 to 14.0 pH]
9660010
BECSys pH Sensor (10’ cable) [ range: 0 to 14.0 pH]
ORP Sensors
9660022
BECSys ORP Sensor Platinum Band (30” cable)
[range: 0 to 1000mV]
9660023
BECSys ORP Sensor Platinum Band (10’ cable)
[range: 0 to 1000mV]
9660038
BECSys ORP Sensor Solid Gold Band (30” cable)
[range: 0 to 1000mV]
9660040
BECSys ORP Sensor Solid Gold Band (10’ cable)
[range: 0 to 1000mV]
Temperature Sensors
8660016
Temperature Sensor (30” cable)
[range: 32°F to 212°F (0°C to 100°C)]
9660003
Temperature Sensor (10’ cable)
[range: 32°F to 212°F (0°C to 100°C)]
pH/ORP Sensor Maintenance Items
8500061
4/KCl solution (pint); for long-term storage of sensors
8680015
½” Wetting Cap for pH and ORP sensors
Sample Stream
Flow Switches
9660006
Reed flow switch [Switch Point (On): 2.0 gpm]
9660007
Rotary flow switch [Switch Point (On): 1.5 gpm]
9060547
Spring Check Valve
Round Flow Cell
1210148
Sample stream for round flow cell with reed flow
switch
1210149
Sample stream for round flow cell with rotary flow
switch
Rectangular Flow Cell
1210142
Sample stream for rectangular flow cell with reed flow
switch
1210143
Sample stream for rectangular flow cell with rotary
flow switch
Lighted Flow Cell
2210529
Sample Stream for lighted flow cell
Optional Sensors - Not shown in diagrams since these sensors
are not installed in the controller sample stream.
Optional OCS140 Free Chlorine Sensor
9660005
Amperometric Sensor only, no flow cell
[range: 0 to 20 ppm]
8680016
Replacement Membranes (2 pieces) for Chlorine
Sensor 9660005
8680017
Electrolyte (50 ml) for Chlorine Sensor 9660005
2220363
Amperometric ppm Probe Nut
Optional CP-1 Free Chlorine Sensor
2210422
Replacement CP-1 Sensor (includes glass beads and
O-rings) [range: 0 to 10 ppm]
Optional Total Chlorine
8660044
Total Chlorine Sensor only, no flow cell
[range: 0 to 20 ppm]
2220359
Probe Ring
2220360
Total Chlorine Probe Nut
2220361
O-Ring Retainer
8060808
O-Ring 3/32x0.987 ID
8060809
O-Ring 3/32x1.174 ID
Optional Pressure and Vacuum
8520189
50ft Cable Pressure or Vacuum Transducer
8520190
100ft Cable Pressure or Vacuum Transducer
8660029
Pressure transducer only, no cable
[range: 0 to 100 PSI]
8660033
Vacuum transducer only, no cable
[range: -14.7 to 85 PSI]
8660064
Pressure transducer only, no cable
[range: 0 to 100 PSI]
8660065
Vacuum transducer only, no cable
[range: -14.7 to 85 PSI]
9660019
Vacuum Swichgage [range: 0 to 30 in. HG]
9660020
Pressure Swichgage [range: 0 – 50 PSI]
8660021
Differential Swichgage [range: 0 – 50 PSI]
Optional Conductivity/TDS
9660012
BECSys Conductivity Sensor
[range: 0 to 20,000 micromho]
Optional Turbidimeter
1210261
BECSys Turbidimeter [range: 0 to 20.00 NTU]
9680024
Dessicant Tray – Refill
Optional Flowmeters
8660008
Flowmeter (1/2” to 4”) [range: 0 to 655.35 Kgpm]
9660009
Flowmeter (5” to 8”) [range: 0 to 655.35 Kgpm]
9660004
Flowmeter (10” to 36”) [range: 0 to 655.35 Kgpm]
Documentation
8620108
BECSys7 Operation and Maintenance Manual
8620111
BECSys7 Installation and Technical Manual
8620038
BECSys7 Laminated Quick Reference Sheet
