Environmental Conditions
The BECSys7 is housed in a NEMA 4X (IP65) enclosure. It should not be used in explosive environments. The
BECSys7 should be mounted so that adequate ventilation is provided around the enclosure, preventing general
environmental specifications from being exceeded (see table below).
Environmental Specifications
Specification
Rating
Storage Temperature
-40 to 85 Deg C
Ambient Operating Temperature
-18 to 50 Deg C
Ambient Humidity
95% non condensing maximum humidity
Electrical Specifications
The BECSys7 may be ordered in either a 115VAC model or a 230VAC model. Following are the electrical specifications
for each model:
Controller Ratings
115VAC Model
230VAC Model
Voltage:
115VAC 60Hz
230VAC 50Hz
Phase:
Single
Single
Current:
32.5 Amps Full Load
32.25 Amps Full Load
(½ Amp – Controller)
(¼ Amp – Controller)
(32 Amps – Relay Outputs: 3A X 8, 8A X 1)
(32 Amps – Relay Outputs: 3A X 8, 8A X 1)
Relay Output Ratings
115VAC Model
230VAC Model
Relay 1 (K1)
250VAC (max) – 3 Amps
250VAC (max) – 3 Amps
Relay 2 (K2)
250VAC (max) – 3 Amps
250VAC (max) – 3 Amps
Relay 3 (K3)
250VAC (max) – 3 Amps
250VAC (max) – 3 Amps
Relay 4 (K4)
250VAC (max) – 3 Amps
250VAC (max) – 3 Amps
Relay 5 (K5)
250VAC/30VDC (max) – 8 Amps
250VAC/30VDC (max) – 8 Amps
Relay 6 (K6)
250VAC/30VDC (max) – 3 Amps
250VAC/30VDC (max) – 3 Amps
Relay 7 (K7)
250VAC/30VDC (max) – 3 Amps
250VAC/30VDC (max) – 3 Amps
Relay 8 (K8)
250VAC/30VDC (max) – 3 Amps
250VAC/30VDC (max) – 3 Amps
Relay 9 (K9)
250VAC/30VDC (max) – 3 Amps
250VAC/30VDC (max) – 3 Amps
Caution: After installation the enclosure must be completely sealed to preserve the NEMA rating,
including sealing unused watertight cable glands. Failure to do so may result in a voided warranty.
