Beechcraft Duchess 76 - Engine and Takeoff Performance

MANIFOLD PRESSURE vs RPM
EXAMPLE:
ENGINE SPEED 2500 RPM
MANIFOLD PRESSURE 19.1 IN. HG
WITHIN RECOMMENDED LIMITS
NON-OPERATING AREA
' .......
OPERATING AREA
