Beechcraft Duchess 76 - Page 173

BEECHCRAFT
Duchess 76
Section VII
Systems Description
SUBJECT
TABLE OF CONTENTS (Continued)
PAGE
Electrical System 7-26
Battery , 7-26
Schematic 7-27
Alternators 7-28
Starters
; 7-29
Starter Engaged Warning Light 7-30
External Power 7-30
Lighting Systems
Interior Lighting 7-34
Exterior Lighting 7-34
Environmental Systems
",,'cabin Heating .. , 7-35
Illustration.
7 -':lR
Heater Operation '" .
Cabin Ventilation :
'oJ'oJ
Overhead Fresh Air Outlets '" 7-38
Exhaust Vent... 7-39
Pitot and Static Systems 7-39
Pitot System 7-39
Pitot Heat...
'" 7-39
Static System 7-40
Pressu
re System 7-40
Stall Warning System 7-41
August, 1980
7-3
