English ⋅ Nautilus
®
T
63
86105 BA-en/00
Casting
Casting with camera
1. Go to "Settings" > "Program" > "Camera".
A symbol in the header of the screen indicates
that the mode is activated (see page 3)
2. Optional: Enter log data (see "Setting up the
protocol" on page 40). This data appears in the
casting protocol that is stored on the con-
nected USB flash drive.
• Enter work number, batch and casting quan-
tity and confirm the entry with "OK" or
• Skip the data entry with "Abort".
3. Insert the alloy.
4. Close the crucible door.
Risk of injury
Wear suitable protective equipment
when operating the device!
Only touch the touchscreen with the
fingertips! Do not use pens or finger-
nails!
Any liquid that leaks as a result of
damage is toxic and corrosive! Avoid
contact with skin, swallowing or
inhaling it!
The device cannot measure the
temperature and thus not limit the
temperature!
Stay with the device and finish the
preheating and melting as described
manually!
