72
86105 BA-en/00
English ⋅ Nautilus
®
CC plus ⋅ Nautilus
®
T
Adding cooling water
The internal device cooling facilitates more than 50
quick successive castings. If the E 020 message is
issued, switch off the device and let it cool.
1. Remove the cover on the left side (loosen the
slotted screws).
2. A shown in the illustration, remove both stop-
pers and take out the funnel.
3. Add approx. 1.5 liters of potable water up to
the "max" marking.
4. Drain excess water as shown!
5. Replace both stoppers.
6. Switch the device on and press the "Automatic
casting" button. Run the device for 2 minutes
to allow for the cooling water to circulate.
7. Switch the device off.
8. Remove both stopper again and check the
cooling water level. Top off with potable water
until it reaches the "max" marking, if neces-
sary.
9. Finally, replace both stoppers and stow the
funnel.
Risk of burns!
The water can reach temperatures up
to 70° C if the device was used for
casting beforehand!
