6.3 Printing Measurement Data
Saving after the measurement result, it is possible
to print the datas. For this, the UNITEST Protocol
Printer (Cat. No. 1196) and the Interface Adapter
(Cat. No. 1157) are required (option).
Selection can be made whether the last saved re-
sult, all results, or part of the results should be prin-
ted.
To print the measurement data, please proceed as
follows:
Perform the desired measurements and save
these measurements by pressing the key
“Store” (17), please refer to section 6.1.
Remove holster
Apply the TELARIS Interface Adapter (Cat. No.
1157) onto the TELARIS 0100 plus.
Connect the serial connection cable with the
protocol printer.
Switch on the printer and set the interface pa-
rameter on the protocol printer in compliance
with the TELARIS 0100 plus .
To print the last saved result, briefly press the
"Print” key (31). "Prt" is displayed on the screen,
the data is transmitted to the protocol printer.
To print all memorised data, press the "Print" key
(31) for a longer time (approx. 3 seconds). "Prt”
is displayed on the screen, The data is trans-
mitted to the protocol printer.
Now, all data is printed starting from the last me-
morised result. During printing, the currently
printed memory address number is displayed
The printout of all results can be cancelled at any
time. This is done by pressing the "Print” key
(31) again during the printing of the last reque-
sted data string. Keep the key pressed until the
print job has been cancelled.
This function allows partial printing of data.
It is important to observe the interface settings
of the protocol printer and accordingly set the
interface parameter of the TELARIS 0100 plus
(9600 Baud, even parity, 8 data bit, 1 stop bit,
1 start bit, please refer to the technical data sec-
tion). Please refer to the instruction manual
supplied with the protocol printer (Cat. No.
1196) for printer parameter setting.
31
Printing Measurement Data
