13.0 Technical Data
General technical data:
Display: 3
1
/2 digit or 3 digit LCD
Reference-Range: +17°C to 27°C, max. 70% rel. humidity
Temperature-Range: 0°C to 40°C, relative humidity max. 80%
Storage temperature: -10°C...+60°C
Height above MSL: up to 2000m
Battery type: 6x 1,5V Mignon Typ IEC LR6 (size AA)
Current-consumption: 20mA (Stand-by)
Battery life: for average use approx. 1 year
Auto-Power-Off: after approx. 5min
Fuses: F1/F2: T 1,26A/500 V 1000 A, 6 x 32 mm
Data memory Interface: 9600 Baud, 1 startbit, 8 data bits, even parity, 1 stoppbit
Overvoltage Category: CAT III / 440V against ground
Pollution degree: 2
Protection Category: 2, IP50
Dimensions: 235 x 103 x 70 mm
Weight: 650g incl. Batteries
Voltage measurement Vac, Vdc:
Measurement Range Vac: 1 ... 440VAC (Frequency f: 10 ... 99.9 Hz)
Measurement Range Vdc: 1 ... ±440VDC
Resolution: 1 V
Tolerance: ±(3% rdg. +3 Digit)
Internal Resistance: 1 MΩ
Frequency Measurement f:
Measurement Range: 10,0 ... 99,9Hz
Resolution: 0,1Hz
Tolerance: ±(1% rdg. +1 Digit)
Voltage Range: 5 ... 440VAC
Low Ω Measurement:
Measurement range: 0,01...19,99 Ω, 20,0 ... 199,9 Ω, 200 ... 1999Ω
Resolution: 0,01 Ω, 0,1Ω, 1Ω
Tolerancy: ± (3% + 5digits)
Output voltage Uq: 4V...9V DC
Test Current: ≥ 200mA (at resistance < 2Ω+Rcomp)
Measurement time: approx. 1s (automatic) (continous)
Number of Measurements: approx. 4000 (1Ω, 1 measurement- 25s break)
Compensated test lead resistance: max. 1,99 Ω
39
