GRIND SysEx information
SYSTEM EXCLUSIVE COMMANDS
Some GRIND parameters can be changed using MIDI system exclusive (SysEx) commands. A MIDI utility such
as MIDI OX can be used to send the SysEx command data string to the GRIND using the USB MIDI connection
between the computer and the GRIND.
MIDI SysEx Messages
The following data format is used when creating a SysEx message, and the various items in this SysEx data
string are described below:
Frame start
F0
Manu ID
00 20 32
Device ID
aa bb cc
PKY
dd
SPKT
ee
Parameter
D0 ... Dn-1
Frame end
F7
Item (Hex) Description
00 20 32 Manufacturer SysEX ID number (Behringer GmbH)
aa bb cc Device ID: 00 01 50 for GRIND
dd It is a main pack et type (abbr. PKT).
ee It is a sub packet type (abbr. SPKT). SPKT is absent for some packets.
D
0
… D
n-1
Parameter value.
Name State Command Para range(D0 … Dn)
Set Pitch Bend
Range
valid
F0 00 20 32 00 01 50 11
D0 D1 F7
D0: The value of pitch bend range is
0x00~0x0C → Semitones 0~12
Default Value: 0x0C
D1: Fixed value 0x00
Set MIDI Clock valid
F0 00 20 32 00 01 50
17 D0 F7
D0: 0x00 → Disable / 0x01 →
Enable
Default Value: 0x00
Set Sequencer
Auto Play
valid
F0 00 20 32 00 01 50
1D D0 F7
D0: 0x00 → Disable / 0x01 →
Enable
Default Value: 0x01
Name State Command Para range(D0 … Dn)
Set Assign Mode valid
F0 00 20 32 00 01 50
1F D0 F7
D0: The value of assign mode is
0x00~0x0F →
0x00: Sequencer Accent
0x01: Sequencer Clock
0x02: Sequencer Clock/2
0x03: Sequencer Clock/4
0x04: Sequencer Step Ramp
0x05: Sequencer Step Saw
0x06: Sequencer Step Triangle
0x07: Sequencer Step Random
0x08: Sequencer Step 1 Trigger
Output
0x09: MIDI Velocity
0x0A: MIDI Channel Pressure
0x0B: MIDI Pitch Bend
0x0C: MIDI CC1
0x0D: MIDI CC2
0x0E: MIDI CC4
0x0F: MIDI CC7
Default Value: 0x00
Set Clock Source valid
F0 00 20 32 00 01 50
1B D0 F7
D0: The value of clock source is
0x00~0x04 →
0x00: INT
0x01: MIDI
0x02: USB
0x03: EXT
0x04: AUTO
Default Value: 0x00
Set Clock Type valid
F0 00 20 32 00 01 50
1A D0 F7
D0: The value of clock type is 0x00~
0x04 →
0x00: 1PPS
0x01: 2PPQ
0x02: 24PPQN
0x03: 48PPQN
0x04: CV
Default Value: 0x00
Set Clock Edge valid
F0 00 20 32 00 01 50
19 D0 F7
D0: The value of clock edge is 0x00~
0x01 →
0x00: Fall
0x01: Rise
Default Value: 0x00
Set Accent
Threshold
valid
F0 00 20 32 00 01 50
1C D0 F7
D0: Enable value 00~7E
Disable value 7F
Default Value: 0x60
