11
SHARK DSP110
20
This is the SHARKs balanced JACK input, which is wired in parallel to the XLR
input.
21
Use the INPUT LEVEL switch to select the input sensitivity (microphone or line
levels). In LINE mode, you can use the CLIP LEVEL control to adapt the internal
level settings to the digital circuitry. Please make sure that the CLIP-LED will
not light up.
22
The PHANTOM switch enables the Phantom Power supply required for
condenser microphones.
23
The PHANTOM CONTROL LED lights up when Phantom Power is on.
2. APPLICATIONS
2.1 Wiring the DSP110: general remarks
With its great versatility the SHARK can be used for a variety of applications. This
chapter describes connection and configuration examples of the most common
applications.
2.1.1 Connection between microphone and mixing console
In live applications it is often useful to protect specific single microphones against
feedback. We therefore recommend that you connect the SHARK between your
microphone and a microphone input on your mixing console (OUTPUT LEVEL switch
set to MIC). If all mic inputs are in use, you can set the SHARKs OUTPUT switch to
+4dBu (switch pressed) and adapt the output signal of your SHARK to a line input on
your console using the MIC GAIN control. To prevent the occurrence of subsonics you
can activate the SHARKs Low Cut filter. Switch on Phantom Power when you are
using condenser microphones.
2. APPLICATIONS
DATA-MANFULL_DSP110_ENG_Rev. E.p65 20.04.01, 15:4511
