22
SHARK DSP110
4. SPECIFICATIONS
AUDIO INPUTS
Connectors XLR and 1/4" jack
Type RF filtered, servo-balanced input
Impedance 6 kOhms balanced, 3 kOhms unbalanced
Nominal Operating Level microphone or line level source (switchable)
Max. Input Level +19 dBu at microphone level and line level
AUDIO OUTPUTS
Connectors XLR and 1/4" jack
Type electronically servo-balanced output stage
Impedance 60 Ohms balanced, 30 Ohms unbalanced
Nominal Operating Level microphone level source or +4 dBu (switchable)
Max. Output Level +20 dBu at +4 dBu nominal level, -12 dBu at microphone level
SYSTEM SPECIFICATIONS
Frequency Response 10 Hz to 21 kHz
Noise > 92 dB at line level, unweighted, 22 Hz to 22 kHz
> 89 dB at microphone level, unweighted, 22 Hz to 22 kHz
THD 0.007 % typ. @ +4 dBu, 1 kHz, gain 1
DIGITAL PROCESSING
Converters 24-bit Sigma-Delta, 64/128-times oversampling
Sampling Rate 46.875 kHz
DISPLAY
Type 4-digit numeric LED display
POWER SUPPLY
Mains Voltages USA/Canada 120 V ~, 60 Hz, PSU DSP110UL
U.K./Australia 240 V ~, 50 Hz, PSU DSP110UK
Europe 230 V ~, 50 Hz, PSU DSP110EU
Japan 100 V ~, 60 Hz, PSU DSP110JP
General export model 100 - 120 V ~, 200 - 240 V ~, 50 - 60 Hz
PHYSICAL
Dimensions (H * W * D) approx. 2 1/4" (56 mm) x 3 1/2" (88 mm) x 5 1/8" (130 mm)
Net Weight approx. 0.5 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts,
modifications may be made from time to time to existing products without prior notice. Specifications and appearance
may differ from those listed or illustrated.
4. SPECIFICATIONS
DATA-MANFULL_DSP110_ENG_Rev. E.p65 20.04.01, 15:4522
