Behringer XENYX 1002FX

ENGLISH
XENYX 1002FX/1202FX User Manual
15
AUDIO OUTPUTS
FX send
Type ¼" TRS connector, unbalanced
Impedance approx. 120 Ω
Max. output level +22 dBu
Main outputs
Type ¼" TRS connector, unbalanced
Impedance approx. 120 Ω
Max. output level +22 dBu
Control room outputs
Type ¼" TRS connector, unbalanced
Impedance approx. 120 Ω
Max. output level +22 dBu
Headphones output
Type ¼" TRS connector, unbalanced
Max. output level +19 dBu / 150 Ω (+25 dBm)
MAIN MIX SYSTEM DATA
Noise
Main mix @ -oo, Channel fader -oo -105 dB / -108 dB A-weighted
Main mix @ 0 dB, Channel fader -oo -94 dB / -97 dB A-weighted
Main Mix @ 0 dB, Channel fader @ 0 dB -83 dB / -85 dB A-weighted
FX section
Converter 24-bit Sigma-Delta
Sampling rate 40 kHz
Power supply
Mains voltage
USA/Canada 120 V~, 60 Hz, MXUL6 adapter
U.K./Australia 240 V~, 50 Hz, MXUK6 adapter
Europe 230 V~, 50 Hz, MXEU6 adapter
China/Korea 220 V~, 50 Hz, MXCN6 adapter
Japan 100 V~, 60 Hz, MXJP6 adapter
Output 2 x 14.8 V~, 2 x 500 mA
Dimensions
1002FX
Dimensions (H x W x D) 1 /" / 1 /" x 7 /" x 8 /"
(47 mm / 37 mm x 189 mm x
220 mm)
Weight (net) approx. 2.31 lbs (1.05 kg)
1202FX
Dimensions (H x W x D) 1 /" / 1 /" x 9 /"x 8 /"
(47 mm / 37 mm x 242 mm x
220 mm)
Weight (net) approx. 2.97 lbs (1.35 kg)
Measuring conditions:
1: 1 kHz rel. to 0 dBu; 20 Hz - 20 kHz;
line input; main output; unity
gain.
2: 20 Hz - 20kHz; measured at main
output. Channels 1 - 4 unity gain;
EQ flat; all channels on main mix;
channels / as far left as possible,
channels / as far right as
possible. Reference = +6 dBu.
BEHRINGER is constantly striving to manintain the highest professional standards. As a result of these efforts,
modifications may be made from time to time to existing products without prior notice. Specifications and
appearance may differ from those listed or illustrated.
