Beijer Electronics Frequency Inverter BFI-H3 KI00363B 2019-09
www.beijer.se www.beijer.no www.beijer.dk www.beijerelectronics.de www.beijerelectronics.com www.beijerelektronik.com.tr 4 (29
)
IP66 drives are fitted with 3 knockout holes for cable inlet and outlet. If more than 3 cables are to
enter the drive it is possible to have two or more cables going through one gland. This is to ensure
IP66.
Holes and recommended glands are listed in table below. The motor cable does not have to be
attached to the drive with an EMC-gland.
4.2 Physical dimensions IP20
BFI-H3-IP20
Drive
size
A
Height
[mm]
B
[mm]
C
[mm]
D
[mm]
E
[mm]
F
Depth
[mm]
G
Width
[mm]
H
[mm]
Weight
[kg]
1 x 230 V 3 x 230 V 3 x 400 V
0043 -
0105
[0,75-2,2kW]
0043 -
0105
[0,75- 2,2kW]
0022 -
0095
[0,75 - 4,0 kW]
2 221 207 137 209 5.3 185 110 63 1,8
None
0180-
0240
[4,0- 5,5kW]
0140 –
0240
[5,5 - 11 kW]
3 261 246 - 247 6 205 131 80 3,5
None
0300 – 046
0
[7,5 - 11 kW]
0300 – 046
0
[15 - 22 kW]
4 418 - 400 240 160 125 9,2
None
0610 – 090
0
[15 - 22 kW]
0610 – 090
0
[30 - 45 kW]
5 486 - 460 260 222 175 18
None
1100 – 150
0
[30 - 37 kW]
1100 – 150
0
[55 - 75 kW]
6A 614 - 578 320 286 200 32
None
1800 – 202
0
[45 - 55 kW]
1800 – 202
0
[90 - 110 kW]
6B 726 - 680 320 330 225 43
None None
3700 – 450
0
[200 - 250 kW]
8 995 480 482 128
NOTE
Mounting bolts
Frame size 2-3: M4 FrameSize 4-5 and 6A: M8
Frame Size 6B: M10 Frame Size 8: M12
Control Terminal, Required Torque All Frame sizes: 0.5 Nm.
Power Terminal, Required Torque
Frame size 2-3: 1 Nm FrameSize 4: 2 Nm
FrameSize 5: 4 Nm Frame Size 6A: 12 Nm Frame
Size 6B: 15 Nm
Cable Gland, IP66 Hole Size & recommended glands
Frame size Hole sizes Gland PG
Size 2
1x22mm & 2x28 mm 1xPG13,5 & 2xPG21
Size 3
1x22mm & 2x28 mm 1xPG13,5 & 2xPG21
